TL SERIES
TLWW24HO
24VDC FLEXIBILE WALL WASHER/GRAZER
The TLWW24HO flexible strip light provides outstanding performance for all your indoor and outdoor wall washing and wall grazing applications. With CRI of 93 and an R9 value of 82, these LED chips offer exceptional color rendering. The color consistency is further ensured by 3-step MacAdam ellipse binning. Our robust silicone housing provides an IP67 fixture that can withstand the toughest exterior conditions.
Technical Specifications
Technical Specs
Operating Voltage
24VDC
Power Consumption
5.9W/ft
Lumens/ft (3000K)
689lm/ft (Symm) / 507lm/ft (Asym)
Efficacy (3000K)
117lm/ft (Symm) / 85lm/ft (Asym)
Color Temperatures
2700K, 3000K, 3500K, 4000K, 5000K
CRI
93
LED Life
30,000+ hrs
LED Chips/ft
13 (Symm) 10 (Asym)
R9 Value
82
Optic
20° (Symm) 110° x 70° (Asym)
Cuttable Increments
6.6"
Maximum Run Length
16.4ft
MacAdam Ellipse Binning
3-step
Warranty
5 years
